Setting up a Web Server Using Docker on Oracle Cloud Infrastructure Ampere arm64 Always Free Instance

ByTim Nolte
3 Comments

After successfully migrating from a Droplet for my instance I decided to take advantage of the remaining resources still available on to migrate my web hosting as well. I’m going to be taking a different approach, basically because of the setup, and using for running most of my hosting setup.

Create New OCI Instance

In the event you want to test out an instance, and reuse the associated IP address without having to update public DNS records, you should first create a reserved IP address. Then during the instance creation choose not to assign a public IPv4 address as you’ll assign it after the instance is created.

  1. Create a new arm64 instance with as many resources as you want.
  2. Select arm64 as the OS. (Note: You can choose a minimal Ubuntu system to keep things lean but will require the addition of other packages. This is my preference so this guide may include installation steps that aren’t needed if you choose a full install.)
  3. Edit settings as you see fit, choose to not assign a public IPv4 address is using an existing reserverd IP address. (See note above)

Install Some Required Packages

I would recommend installing the dialog package in order to provide console screens for package configuration.

$ sudo apt install dialog

I prefer to setup my system with so that is usually one of the first packages I install to use to edit configuration files during the setup.

$ sudo apt install neovim

After these updates you will most likely be instructed to reboot the server.

$ sudo reboot

Install and Update System

Recently my preference for system package management has been the nala package manager.

$ sudo apt update
$ sudo apt install nala

Per the nala installation instructions you can setup nala to fetch from the most responsive mirrors closest to you.

$ sudo nala fetch

Afterwards you can use nala to update the system.

$ sudo nala update
$ sudo nale upgrade

Afterwards you should perform a system reboot.

$ sudo reboot

Note: I will be using nala for package management in most cases throughout the rest of this guide.

Install Latest Docker Engine

Docker is included in many distributions but I want to make sure that the latest versions are being installed directly from Docker for continual updates. You can follow the official documentation for installing on Ubuntu and Debian-based distributions.

$ sudo nala remove docker docker-engine docker.io containerd runc

Note: It is OK if this step indicates that there is nothing to remove.

Install Using The Repository

First install Docker required packages.

$ sudo nala install ca-certificates curl gnupg lsb-release

Note: It is OK if this step results in no new packages added.

Setup The Repository

$ sudo mkdir -p /etc/apt/keyrings
$ curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg
$ echo \
  "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] https://download.docker.com/linux/ubuntu \
  $(lsb_release -cs) stable" | sudo tee /etc/apt/sources.list.d/docker.list > /dev/null

Install Docker Engine

Check for package updates and install the Docker packages.

$ sudo chmod a+r /etc/apt/keyrings/docker.gpg
$ sudo nala update
$ sudo nala install docker-ce docker-ce-cli containerd.io docker-compose-plugin

After the Docker installation you’ll want to reboot the OCI instance.

$ sudo reboot

Basic Security Configuration

Installing And Configuring fail2ban

This is basically the same setup as I used for the Mastodon instance setup on OCI to setup .

Installing Mastodon on an Oracle Cloud Infrastructure Ampere arm64 Always Free Instance

Here’s a quick command rundown.

$ sudo nala install fail2ban
$ sudo vi /etc/fail2ban/jail.local
$ sudo reboot

Installing And Configuring The iptables Linux Firewall

As mentioned in the above post the Linux firewall should already be setup with the Ubuntu system install. I did setup the IPv6 firewall rules to begin allowing traffic via IPv6. I used the initial Mastodon IPv6 configuration.

$ sudo vi /etc/iptables/rules.v6
#  Allow all loopback (lo0) traffic and drop all traffic to 127/8 that doesn't use lo0
-A INPUT -i lo -j ACCEPT
-A INPUT ! -i lo -d ::1/128 -j REJECT

#  Accept all established inbound connections
-A INPUT -m state --state ESTABLISHED,RELATED -j ACCEPT

#  Allow all outbound traffic - you can modify this to only allow certain traffic
-A OUTPUT -j ACCEPT

#  Allow HTTP and HTTPS connections from anywhere (the normal ports for websites and SSL).
-A INPUT -p tcp --dport 80 -j ACCEPT
-A INPUT -p tcp --dport 443 -j ACCEPT

#  Allow SSH connections
#  The -dport number should be the same port number you set in sshd_config
-A INPUT -p tcp -m state --state NEW --dport 22 -j ACCEPT

#  Allow ping
-A INPUT -p icmpv6 -j ACCEPT

#  Log iptables denied calls
-A INPUT -m limit --limit 5/min -j LOG --log-prefix "iptables denied: " --log-level 7

#  Reject all other inbound - default deny unless explicitly allowed policy
-A INPUT -j REJECT
-A FORWARD -j REJECT

After the configuration edit, you just need to load it into iptables. I rebooted just to make sure everything was set.

$ sudo ip6tables-restore < /etc/iptables/rules.v6
$ sudo reboot

#Portainer Installation with Nginx Proxy Manager and SSL

Figuring out a setup to easily manage SSL, using Let’s Encrypt, as well as handle running services all on Docker took many iterations. If I was going to be using Docker to run OpenLiteSpeed then I didn’t need all of the overhead of many of the web control panels. I tried Cockpit and Virtualmin as I had either used them in the past or they came highly recommended. I came across some documentation on using the Nginx Proxy Manager and it seemed like the lightweight setup I was after. The nice thing about it is that the general setup of it is running it via Docker. I liked this idea as it meant I didn’t have to setup and maintain Nginx locally on the server instance.

Nginx Proxy Manager Installation

References:

$ sudo mkdir -p /var/lib/nginx-proxy-manager/data
$ sudo mkdir /etc/letsencrypt
$ sudo docker network create services-network
$ sudo vi /var/lib/nginx-proxy-manager/docker-compose.yml

docker-compose.yml

version: "3.5"
services:
  npm:
    image: 'jc21/nginx-proxy-manager:latest'
    restart: unless-stopped
    networks:
     - default
    ports:
      # These ports are in format <host-port>:<container-port>
      - '80:80' # Public HTTP Port
      - '443:443' # Public HTTPS Port
      # - '81:81' # Admin Web Port
      # Add any other Stream port you want to expose
      # - '21:21' # FTP

    # Uncomment the next line if you uncomment anything in the section
    # environment:
      # Uncomment this if you want to change the location of
      # the SQLite DB file within the container
      # DB_SQLITE_FILE: "/data/database.sqlite"

      # Uncomment this if IPv6 is not enabled on your host
      # DISABLE_IPV6: 'true'

    volumes:
      - /var/lib/nginx-proxy-manager/data:/data
      - /etc/letsencrypt:/etc/letsencrypt
      - /var/lib/letsencrypt:/var/lib/letsencrypt
      - /var/log/letsencrypt:/var/log/letsencrypt

networks:
 default:
   name: services-network
$ sudo docker compose -f /var/lib/nginx-proxy-manager/docker-compose.yml up -d

Add an OCI Ingress Rule for Access

You will need to set Ingress rules for your Oracle Virtual Cloud Network to temporarily allow web traffic for the Nginx Proxy Manager default port 81. The basic run down is as follows:

  1. Open the navigation menu and click Networking, and then click Virtual Cloud Networks.
  2. Select the VCN you created with your compute instance.
  3. With your new VCN displayed, click <your-subnet-name> subnet link.The public subnet information is displayed with the Security Lists at the bottom of the page. A link to the Default Security List for your VCN is displayed.
  4. Click the Default Security List link.The default Ingress Rules for your VCN are displayed.
  5. Click Add Ingress Rules.An Add Ingress Rules dialog is displayed.
  6. Fill in the ingress rule with the following information.Fill in the ingress rule as follows:
    • Stateless: CheckedSource Type: CIDRSource CIDR: 0.0.0.0/0IP Protocol: TCPSource port range: (leave-blank)Destination Port Range: 81Description: Allow HTTP connections
    Click Add Ingress Rules. Now HTTP connections are allowed. Your VCN is configured for Apache server.

Login to the Nginx Proxy Manager at http://<public-ip>:81.

Default Admin User:

Email: admin@example.com
Password: changeme

After you login update/create your admin account.

Secure the Nginx Proxy Manager via SSL

References:

  • Navigate to the Nginx Proxy Manager “Host” section and choose to “Add Proxy Host”.
  • Enter the subdomain you’d like to use to access the Nginx Proxy Manager. (i.e. admin.example.com)
    • Note: ensure that this domain name is configured via your DNS services to point to the OCI instance IP address or as a CNAME record.
  • Enter the Docker service name(i.e. npm) of the Nginx Proxy Manager and port 81 for the “Forward Port”.
  • Turn on “Block Common Exploits” and “Websockets Support”.
  • Under the “SSL” section choose to “Request a new SSL Certificate” and “Agree to the Let’s Encrypt Terms of Service”.
  • Save the new Proxy Host settings.

You should now be able to login via the custom subdomain over SSL. At this point I would remove the OCI Ingress rule added to allow port 81 and restrict all access to only SSL.

Installing Portainer

References:

Preparing and Starting Portainer

$ sudo mkdir -p /var/lib/portainer/data
$ sudo vi /var/lib/portainer/docker-compose.yml
docker-compose.yml
version: "3.5"
services:
  portainer:
    image: portainer/portainer-ee:latest
    command: -H unix:///var/run/docker.sock
    restart: unless-stopped
    networks:
      - default
    # ports:
      # These ports are in format <host-port>:<container-port>
      # - '8000:8000' # Public HTTP Port
      # - '8080:9000' # Public HTTP Port
      # - '9443:9443' # Public HTTPS Port

    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
      - /var/lib/portainer/data:/data

networks:
 default:
   name: services-network
$ sudo docker compose -f /var/lib/portainer/docker-compose.yml up -d

Securing Portainer via SSL Using Nginx Proxy Manager

The first thing to do is to setup a new Proxy Host in the Nginx Proxy Manager for Portainer to create the SSL certificate.

  • Navigate to the Nginx Proxy Manager “Host” section and choose to “Add Proxy Host”.
  • Enter the subdomain you’d like to use to access the Nginx Proxy Manager. (i.e. containers.example.com)
    • Note: ensure that this domain name is configured via your DNS services to point to the OCI instance IP address or as a CNAME record.
  • Enter the Docker service name(i.e. portainer) of the Portainer service and port 9000 for the “Forward Port”.
  • Turn on “Block Common Exploits” and “Websockets Support”.
  • Under the “SSL” section choose to “Request a new SSL Certificate” and “Agree to the Let’s Encrypt Terms of Service”.
  • Save the new Proxy Host settings.

Upgrading the Portainer Stack

In order to upgrade Portainer itself you’ll need to stop the Portainer stack, you can do this from the stack details screen in Portainer.

Pull the Latest Portainer Image
$ sudo docker pull portainer/portainer-ee:latest
Startup the Portainer Stack
$ sudo docker compose -f /var/lib/portainer/docker-compose.yml up -d

Installing a MariaDB Server With Docker Using Portainer

Now that Portainer is setup and running we’ll go ahead and get a database server running in order for the web servers, and sites, use it. We will also additionally setup phpMyAdmin for web management.

References:

Create a Persistent Volume for the Database Storage

Navigate to “Volumes” and give it a name (i.e. mariadb).

Create a new MariaDB Container

  1. Navigate to “Containers” and “Add container”.
  2. Give it a name (i.e. mariadb)
  3. Enter mariadb:10.10 for the image.
  4. Map the server ports using “Manual network port publishing” using the standard 3306 port for both host and container.
  5. Under the “Advanced container settings” got to “Volumes” and “map additional volume” using /config for the container and choose the previously created volume name from the volume dropdown menu.
  6. Navigate to the “Network” section and set the network to the previously created services-network.
  7. Then navigate to the “Env” section to define environment variables. Switch to “Advanced Mode” in order to easily add as many needed variables.
    • PUID=1000
    • PGID=1000
    • MYSQL_ROOT_PASSWORD=<password>
  8. Navigate to the “Restart policy” and set to “Unless stopped”.
  9. Finally click on “Deploy the container”

Setup a phpMyAdmin Service

  1. Navigate to “Containers” and “Add container”.
  2. Give it a name (i.e. phpmyadmin)
  3. Enter phpmyadmin:latest for the image.
  4. Map the server ports using “Manual network port publishing” using 8080 for the host port and 80 for the container port.
  5. Navigate to the “Network” section and set the network to the previously created services-network.
  6. Then navigate to the “Env” section to define environment variables. Switch to “Advanced Mode” in order to easily add as many needed variables.
    • MYSQL_ROOT_PASSWORD=<password>
  7. Navigate to the “Restart policy” and set to “Unless stopped”.
  8. Finally click on “Deploy the container”

Securing the phpMyAdmin Service with Nginx Proxy Manager

  • Navigate to the Nginx Proxy Manager “Host” section and choose to “Add Proxy Host”.
  • Enter the subdomain you’d like to use to access the Nginx Proxy Manager. (i.e. db.example.com)
    • Note: ensure that this domain name is configured via your DNS services to point to the OCI instance IP address or as a CNAME record.
  • Enter the Docker service name(i.e. phpmyadmin) of the phpMyAdmin server and port 80 for the “Forward Port”.
  • Turn on “Block Common Exploits” and “Websockets Support”.
  • Under the “SSL” section choose to “Request a new SSL Certificate” and “Agree to the Let’s Encrypt Terms of Service”.
  • Save the new Proxy Host settings.

Installing a Redis Server With Docker Using Portainer

This setup is going to leverage the Portainer “App Templates” feature to quickly spin up a instance.

  • Navigate to “App Templates”.
  • Search for “redis”.
  • Select the “Redi” template.
  • Give the new service a name (i.e. redis), depending on how you plan to use the instance.
  • Set the Network to services-network.

Optional

If you’d like to access the Redis server via tools outside of the Docker environment you’ll want to map a port to the host OCI instance. Click on “Show advanced options” to then set the host port to 6379.

Lastly, click on “Deploy the container”.

Installing The OpenLiteSpeed Web Server With Docker Using Portainer

Preliminary Setup Work

We are going to manage the OpenLiteSpeed server data via the Docker host system similar to the setup of Nginx Proxy Manager and Portainer.

$ sudo mkdir /var/lib/openlitespeed

Create The OpenLiteSpeed Container in Portainer

For this setup we are going to use the docker-compose.yml example from the LiteSpeedTech GitHub repository as our guide.

  1. Navigate to “Containers” and “Add container”.
  2. Give it a name (i.e. openlitespeed)
  3. Enter ghcr.io/ndigitals/openlitespeed:1.7.16-lsphp80 for the image. (note: Currently LiteSpeed doesn’t provide an official arm64 Docker image so I ended up building an image specifically for arm64. See: Supporting OpenLiteSpeed on arm64 with Docker)
  4. Under the “Advanced container settings” go to “Volumes” and “map additional volume” and add “bin” mappings that follow the list as mentioned in the OLS example repository. The only difference is that we are going to prepend all of the host paths with /var/lib/openlitespeed. The following format is the Docker Compose format of host:container, however in Portainer they are listed in reverse.
    • /var/lib/openlitespeed/lsws/conf:/usr/local/lsws/.conf
    • /var/lib/openlitespeed/lsws/admin-conf:/usr/local/lsws/admin/.conf
    • /var/lib/openlitespeed/sites:/var/www/vhosts
    • /etc/letsencrypt:/root/.acme.sh (note: mark this one Read-only, since the Nginx Proxy Manager takes care of managing the certificates.)
    • /var/lib/openlitespeed/logs:/usr/local/lsws/logs
  5. Navigate to the “Network” section and set the network to the previously created services-network.
  6. Then navigate to the “Env” section to define environment variables. Switch to “Advanced Mode” in order to easily add as many needed variables.
    • TZ=America/New_York (note: you’ll want to set this to an appropriate timezone for your location.)
  7. Navigate to the “Restart policy” and set to “Unless stopped”.
  8. Finally click on “Deploy the container”

Securing the OpenLiteSpeed Web Console with Nginx Proxy Manager

  • Navigate to the Nginx Proxy Manager “Host” section and choose to “Add Proxy Host”.
  • Enter the subdomain you’d like to use to access the Nginx Proxy Manager. (i.e. ols.example.com)
    • Note: ensure that this domain name is configured via your DNS services to point to the OCI instance IP address or as a CNAME record.
  • Enter the Docker service name(i.e. openlitespeed) of the OpenLiteSpeed service and https set for the Scheme as well as port 7080 for the “Forward Port”.
  • Turn on “Block Common Exploits” and “Websockets Support”.
  • Under the “SSL” section choose to “Request a new SSL Certificate” and “Agree to the Let’s Encrypt Terms of Service”.
  • Save the new Proxy Host settings.

Securing the OpenLiteSpeed Web Server Primary Domain Name with Nginx Proxy Manager

  • Navigate to the Nginx Proxy Manager “Host” section and choose to “Add Proxy Host”.
  • Enter the subdomain you’d like to use to access the Nginx Proxy Manager. (i.e. example.com & www.example.com)
    • Note: ensure that this domain name is configured via your DNS services to point to the OCI instance IP address or as a CNAME record.
  • Enter the Docker service name(i.e. openlitespeed) of the OpenLiteSpeed service and port 8088 for the “Forward Port”.
  • Turn on “Block Common Exploits” and “Websockets Support”.
  • Under the “SSL” section choose to “Request a new SSL Certificate” and “Agree to the Let’s Encrypt Terms of Service”.
  • Save the new Proxy Host settings.

Additional Resources

Many of the follow-up items I listed at the end of the Mastodon on OCI setup guide were also applied here. In addition to those items here are some more things to consider:

  • Portainer Authenticated Docker Hub Registry Access – In order to address public Docker Hub rate limiting when pulling Docker images via Portainer you can setup authenticated access. There are still limits when using a free Docker Hub account. (see official Portainer documentation also)
  • Real IP Addresses in OLS Behind Nginx Proxy – In order to address issues of only getting the Docker network IP addresses when OLS is behind the Nginx Proxy you need to set Use Client IP in Header to Yes under the OpenLiteSpeed WebAdmin Console > Server Configuration > General Settings.
  • Server Update Notifications – In order to ensure that the underlying instance is kept secure it is important that updates, especially security updates, are applied in a timely manager. Apticron is a tool that can be used to send an email to notify you of available updates.
    • After the package installation you’ll want to copy /usr/lib/apticron/apticron.conf to /etc/apticron/apticron.conf and make the required changes.
  • Keycloak Docker Container Setup – I had previously setup a Keycloak container under CyberPanel to do some OpenID Connect testing, getting this running under the new setup proved to be challenging since it had been so long ago that I had setup the old one.
  • Low Disk Space Notifications – OCI doesn’t appear to have alarm monitoring for disk usage, additionally for monitoring an instance you are limited to only 2 alarms on the free tier. So some internal server monitoring setup is required.

Technical Architect

A Christ-follower, husband, father, and WordPress Developer with Forum One.

Similar Posts

First Training Run Since Sierra Leone
/

First Training Run Since Sierra Leone

ByTim Nolte
Got my first run in since coming back from #SierraLeone after trying to recover from jet lag and a cold. Felt great to be back out there, definitely with a whole new perspective of why I’m running. Spent a lot of time thinking about those I encountered in Sierra Leone as well as those running in the Bay Shore run today. #HWI #HessLakeRun #GRMarathon #Run4Water
New House…It’s Remodel Time
/ /

New House…It’s Remodel Time

ByTim Nolte
So this Monday we took possession of our new home. While technically it was move in ready it needs a lot of updating. So we have 3-4 weeks before we need to be out of our rental and we’ll be working away to do as much remodel work as we can before we officially move in. Last night I got the range hood removed and counter extension removed. Tonight I checked the measurements of the new over-the-range microwave and what work was going to be involved with getting the cabinets modified and the microwave installed. I’ll post later once that project is in full swing. The main focus tonight was getting the old fridge and stove moved out and checking into the water situation for…
The Christian Responsibility to the Oppressed
/ /

The Christian Responsibility to the Oppressed

ByTim Nolte
– These days there is a lot of talk about the less fortunate and especially the oppressed. It’s very clear from Scripture that as Christian’s we are to defend, and stand against the oppression that we see. To be clear, however, any stand that we make needs to follow biblical principles, not the rights that the world has made up. Unfortunately, following biblical principles is not how the world wants Christians to stand against oppression.
Breaking Out The Facemask For A Chilly Interval Run
/

Breaking Out The Facemask For A Chilly Interval Run

ByTim Nolte
With as cold and windy as it was the previous day, for a short 3+ mile run, today’s temperature and longer run definitely called for putting on the facemask. #HWI #Run4Water #WhyIRun #GRGus Almost a couple of years ago now, I had the honor to travel to Sierra Leone Africa, and witness first hand the impact that clean water has. If you ever have the opportunity to take a trip like that it’s one you can’t pass up. In some ways, unless you’ve actually been there first hand to experience it, it can be very hard to really understand what it means, and the life change that occurs, from access to clean water. Can you imagine the possibilities of a world where everyone has access…
Strength To Get Us Through Anything
/ /

Strength To Get Us Through Anything

ByTim Nolte
When we set out on a run we never know how it’s going to go. We’re going to have good days and we’re going to have bad days. Regardless of how things go we have a God by our side that can get us through those tough hills, unexpected pains, or the feelings of giving up, and bring us across the finish line.
Doing A Long Tuesday Run
/

Doing A Long Tuesday Run

ByTim Nolte
It was a nice long run this morning. I had the worship workout music going and had some solid time with God. Hopefully I’ll get one more of these runs in before I have to take a break from running. #HWI #Run4Water #WhyIRun #GRMarathon

3 Comments

Leave a Reply

Your email address will not be published. Required fields are marked *

This site uses Akismet to reduce spam. Learn how your comment data is processed.
